The Phoenix Contact 3036369 Fused Terminal Block 500V 6.3A Black ST 4-HESI is a premium solution designed for industrial electrical applications. Engineered with precision, this terminal block offers a robust, vibration-resistant connection point for electrical wiring in demanding industrial settings. With a voltage rating of 500V and a maximum current capacity of 6.3A, it ensures optimal performance, safety, and circuit protection for your control systems.
The durable black polyamide housing provides excellent thermal stability and resistance to harsh industrial environments, making it ideal for standard electrical enclosure installations. The ST 4-HESI designation highlights its compatibility with standard industrial wiring practices, offering seamless integration into existing DIN rail assemblies. This fused terminal block is an essential component for electrical professionals seeking a high-quality, dependable solution for industrial circuit isolation.
Incorporating advanced materials and engineering, this Phoenix Contact Fused Terminal Block is a vital component for industrial electrical panels. Its 500V rating ensures compatibility with diverse automation voltage requirements, while the 6.3A handling capacity meets the protection demands of industrial machinery, solenoids, and equipment. The black colour easily distinguishes it as a fused disconnect point within your layout.
The ST 4-HESI designation ensures strict adherence to international industrial standards, facilitating quick and compliant integration into electrical systems. With reliability at its core, this terminal block features a gas-tight spring clamp mechanism that maintains secure contact force over time. Choose the Phoenix Fused Terminal Block for a dependable, maintenance-free solution that meets the stringent demands of modern industrial installations.
Phoenix Contact 3036369 Fused Terminal Block 500V 6.3A Black ST 4 HESI Features:
-
Integrated Fuse Protection: Features a secure lever-action fuse holder designed specifically for standard 5x20 mm cartridge fuses.
-
Vibration Resistant: High-grade spring-cage technology ensures reliable, gas-tight wire connections without the need for periodic re-tightening.
-
Standard Mounting: Snaps effortlessly onto universal NS 35/7.5 and NS 35/15 DIN rails.
-
Extreme Temperature Resistance: Certified for operational environments ranging from -60°C up to 110°C.
-
Potential Distribution: Designed with dual function shafts to accommodate plug-in bridges for quick system expansion.
Specifications
-
Color: Black
-
Number of Levels: Single
-
Model/Series: ST 4-HESI (5X20)
- MPN: 3036369
-
Wire Gauge Range: 28 AWG to 10 AWG (0.08 mm² to 6 mm² solid / 4 mm² stranded)
-
Termination Method: Spring Clamp (Spring-Cage)
-
Fused: Yes (5x20 mm glass or ceramic cartridge fuses)
-
Voltage Rating: 500 V
-
Current Rating: 6.3A
