The Merlin Gerin Auxiliary Contact, identified by model 26925, is a versatile electrical accessory designed to complement circuit breakers and provide additional functionality. In this case, the auxiliary contact features one normally open (1NO) contact configuration, meaning it opens or closes in response to the status of the connected circuit breaker.
With a voltage rating of 240V and a current rating of 6A, this auxiliary contact is suitable for low-voltage applications. It can be used to remotely indicate the status of the associated circuit breaker, providing information about whether the breaker is in the open or closed position. This type of auxiliary contact is commonly used in control circuits and automation systems to monitor and control the status of electrical devices.
Merlin Gerin Auxiliary Contact 1OC 240V 6A 26925 Features:
- Product or Component Type: OC Contact
- Device Short Name: OF
- Signal Contacts Composition: 1 C/O
- 9mm Pitches: 1
- Mounting Mode: Fixed
- Mounting Support: DIN Rail
- Wire Stripping Length: 9mm
- Tightening torque: 1 N.m
- Connections - Terminals:
- Pad Terminal1 Cable(s) 2.5mm² - Rigid
- Pad Terminal2 Cable(s) 1.5mm² - Tigid
- [In] Rated Current:
- AC-12 6A at 220...240VAC 50/60 Hz
- DC-12 1A at 130VDC
- DC-12 1.5A at 60VDC
- DC-12 2A at 48VDC
- AC-12 3A at 277VAC 50/60 Hz
- DC-12 6A at 12...24VDC
- Discontinued Product
