Industrial automation thrives on precision, reliability, and consistency. Among the tools that ensure seamless machine operation, proximity sensors are indispensable. One standout product is the Omron E2E-X5ME1-M1 Proximity Sensor. Known for its durability, accuracy, and compatibility with a wide range of applications, this sensor has become a go-to solution for engineers, technicians, and automation specialists.
In this comprehensive blog, we’ll explore everything you need to know about the Omron E2E-X5ME1-M1 Proximity Sensor: its features, specifications, compatible accessories, mounting options, and common applications. Whether you’re looking to understand its datasheet in detail or identify how it can improve your system’s performance, this guide is your one-stop resource.
What is the Omron E2E-X5ME1-M1 Proximity Sensor?
The Omron E2E-X5ME1-M1 Proximity Sensor belongs to Omron’s E2E series, a globally trusted line of inductive sensors work. Designed for non-contact detection of metallic objects, this sensor ensures precision in automation processes where accuracy and speed are crucial. With a 5 mm sensing distance, NPN output, and robust build quality, it provides both versatility and reliability in challenging industrial environments.
Key Features of Omron E2E-X5ME1-M1 Proximity Sensor
● 5 mm sensing distance: Optimized for ferrous targets, ensuring reliable detection.
● NPN Normally Open output: Ideal for integration in circuits requiring open-collector switching.
● Voltage range: Operates at 12–24 V DC, making it compatible with most automation setups.
● Frequency response: Up to 400 Hz for fast detection in high-speed operations.
● Durable housing: Nickel-plated brass body with PBT sensing face.
● Protection: Built-in short-circuit protection.
● Environmental rating: IP67, suitable for dusty and wet industrial environments.
Detailed Datasheet Specifications
Electrical Characteristics
● Operating voltage: 12–24 V DC (range 10–30 V)
● Ripple: ≤10% p-p
● Output current: 3–100 mA
● Residual voltage: ≤3 V at 100 mA
● Current consumption: ≤0.8 mA (no load)
● Response frequency: Approx. 400 Hz
● Output type: NPN open collector, Normally Open
Mechanical & Environmental Ratings
● Housing: Nickel-plated brass
● Sensing face: PBT resin
● Connection: M12, 3-pin male connector
● Operating temperature: –25 °C to +70 °C
● Storage temperature: –40 °C to +85 °C
● Humidity: 35–95% RH (non-condensing)
● Protection rating: IP67 (dust- and water-proof)
● Vibration resistance: 10–55 Hz, 1.5 mm amplitude
● Shock resistance: 500/1000 m/s²
Physical Dimensions
● Threaded barrel: M18 × 1
● Overall length: Approx. 48 mm
● Weight: ~40 g
● Accessories included: 2 clamping nuts + washer
Compatible Accessories and Mounting Options
When installing the Omron E2E-X5ME1-M1 Proximity Sensor, the right accessories ensure secure and efficient integration.
Mounting Brackets
● Y92E-B18: Bracket designed for M18 proximity sensors, providing stable mounting options.
Mounting Nuts & Washers
● Y92E-NWM18-E2E: Set of clamping nuts and washer for M18 sensors, included but also available separately.
Protective Covers
● Y92E-E18M: Protective cover for unshielded M18 sensors, safeguarding the sensor face in harsh environments.
Cables and Connectors
● XS2F-M12 series: M12 female cables (3-pin/4-pin variants) for connecting the sensor to control systems.
● Omron’s pre-wired connector solutions ensure reliable and quick integration.
Typical Applications of Omron E2E-X5ME1-M1 Proximity Sensor
The Omron E2E-X5ME1-M1 Proximity Sensor is widely used across industries, particularly in:
1. Automotive Manufacturing
Used for detecting presence or absence of metal components during assembly, ensuring accuracy and quality control.
2. Packaging Lines
Ensures precise detection of metallic parts such as cans, foils, or machine components in high-speed packaging processes.
3. Robotics and Automation Systems
Functions as a positioning and limit sensor, helping robots and automated systems achieve accuracy in repetitive tasks.
4. Conveyor Systems
Monitors the passage of metallic objects to regulate speed, flow, and spacing in logistics and production environments.
5. Machine Tools and CNC Equipment
Detects metal workpieces in machining processes, contributing to precision and safety in industrial workshops.
Why Choose the Omron E2E-X5ME1-M1 Proximity Sensor?
The Omron E2E-X5ME1-M1 Proximity Sensor stands out because it balances affordability, robust build, and precision. Its compact size allows for easy integration, while its durability ensures longevity in harsh industrial settings. Moreover, its NPN-NO configuration is compatible with numerous automation systems, making it a flexible choice for engineers and system integrators.
Conclusion: Enhancing Precision with Omron E2E-X5ME1-M1
In industrial automation, reliability and accuracy are non-negotiable. The Omron E2E-X5ME1-M1 Proximity Sensor delivers both, with strong performance across diverse applications. From manufacturing lines to robotics, its role in detecting metallic objects ensures processes remain smooth and efficient.
If you’re looking to integrate this sensor into your automation setup, reviewing its full datasheet and considering the right mounting accessories will help you maximize its performance. To learn more or explore technical details further, visit the product page of the Omron E2E-X5ME1-M1 Proximity Sensor.
