The Omron S8VK-C06024 power supply is one of the most reliable and cost-effective switch mode power supplies available for industrial automation, control panels, and factory equipment. With its compact DIN-rail mounting design and robust 24V DC output, this model has become a trusted choice for engineers and businesses seeking efficiency, safety, and global compatibility.
In this blog, we’ll explore everything you need to know about the Omron S8VK-C06024 power supply—from its specifications and certifications to its practical applications and how it compares with similar models in Omron’s lineup.
What is the Omron S8VK-C06024 Power Supply?
The Omron S8VK-C06024 power supply is a 60W single-output switch mode DIN rail power supply. It converts a wide range of AC or DC input voltages into a stable 24V DC output. This unit is part of Omron’s S8VK-C series, also known as the “Lite” series, designed to balance cost efficiency with quality and performance.
This power supply is engineered for reliability in harsh industrial environments, offering stable output for a wide range of control and automation devices.
Specifications of Omron S8VK-C06024 Power Supply
Key Electrical Specifications
● Input Voltage: 85–264V AC, 90–350V DC
● Output Voltage: 24V DC (adjustable via front potentiometer)
● Output Current: 2.5A
● Power Rating: 60W
● Efficiency: 88%
● Ripple & Noise: 70mV
Mechanical & Environmental Specifications
● Mounting: DIN Rail (35mm standard)
● Dimensions: 90mm x 110mm x 32mm
● Weight: ~300g
● Operating Temperature: -25°C to +60°C
● Cooling Method: Natural convection (no fan)
● Ingress Protection: IP20 (finger safe)
Safety and Protections
● Overcurrent protection (constant current mode)
● Overvoltage protection
● Short-circuit protection
● Overtemperature shutdown with auto recovery
The Omron S8VK-C06024 power supply guarantees both safety and efficiency, ensuring devices downstream are protected against surges, overloads, and environmental challenges.
Certifications and Compliance
The Omron S8VK-C06024 comes with extensive certifications and compliance approvals, making it suitable for global use:
● UL508 Listed (Industrial Control Equipment)
● UL/CSA 60950-1 Recognized
● CSA C22.2 No.107.1 and No.60950-1
● EN50178 and EN60950-1 (Europe)
● SELV (Safety Extra Low Voltage) compliant
● CE Marked
● RoHS Compliant
● EN61204-3 EMC Standard Compliance
● EN55011 Class A EMC
● FCC Class A
● SEMI F47-0706 Compliance (voltage sag immunity)
This wide range of approvals ensures safe integration into global manufacturing and control systems.
Applications of Omron S8VK-C06024 Power Supply
The Omron S8VK-C06024 power supply is ideal for applications that demand reliability at an affordable cost. Typical use cases include:
● PLC Controllers – powering PLC units in control systems.
● Sensors and I/O Modules – providing stable 24V supply to field devices.
● HMI Panels – powering displays and control interfaces.
● Relays and Contactors – energizing low-power coils and control relays.
● Factory Automation Systems – including conveyors, packaging equipment, and robotics.
● Building Automation – HVAC systems, lighting controls, and security systems.
● Process Industry Control Cabinets – stable power for instrumentation.
With its compact DIN-rail design and wide input range, it can be used globally in industrial plants, building systems, and machine control environments.
Technical Datasheet Summary
From the official datasheet, the Omron S8VK-C06024 power supply includes:
● MTBF (Mean Time Between Failures): Hundreds of thousands of hours
● Hold-up Time: ~115 ms at 230V input
● Startup Rise Time: ~0.5s at 115V input
● Line Regulation: ≤0.5%
● Load Regulation: ≤1.5%
● Output Voltage Adjustment Range: -10% to +15%
● Protection Features: OCP, OVP, SCP, OTP
● Vibration Resistance: Up to 5G
● Shock Resistance: Up to 150m/s²
These values show how Omron designed this power supply for durability and reliability even in challenging industrial environments.
Comparison with Other Omron Power Supply Models
Omron offers several families of power supplies, each tailored to specific needs. Here’s how the Omron S8VK-C06024 power supply compares with others:
S8VK-C Series (“Lite”)
● Designed for cost efficiency
● Compact and reliable
● Ideal for cost-sensitive projects
● -25°C to +60°C operating range
● Class A EMC only
S8VK-G Series (“Standard”)
● Wider operating temperature: -40°C to +70°C
● EN55011 Class B EMC (stricter emission standard)
● Parallel operation supported
● Power boost capability (up to 120% rated current)
● Marine certifications
S8VK-T Series (Three-phase)
● For 380–480V AC three-phase input
● Wider power range (≥120W)
● Class B EMC
● Built for higher power and redundancy setups
For applications requiring parallel operation, Class B EMC, or extreme temperatures, the S8VK-G is the better choice. But for most industrial automation needs, the S8VK-C06024 provides all the essential features at a lower cost.
FAQs About Omron S8VK-C06024 Power Supply
1. What is the main advantage of the Omron S8VK-C06024 power supply?
The biggest advantage is its balance of cost, size, and reliability. It provides stable 24V DC power in a compact package without unnecessary extra features, making it affordable yet dependable.
2. Can I use the Omron S8VK-C06024 in residential environments?
No. The S8VK-C series is rated for EN55011 Class A EMC, which is suitable for industrial environments. For residential or commercial spaces, Omron recommends the S8VK-G series.
3. Does the Omron S8VK-C06024 support parallel operation?
No. The S8VK-C series does not support direct parallel operation. For redundancy or higher current, use Omron’s S8VK-G series or an external redundancy module.
4. Is the output voltage adjustable?
Yes. The unit includes a front adjustment potentiometer, allowing fine-tuning of output from about -10% to +15% of 24V.
5. How long is the warranty?
Omron offers a 5-year warranty on the S8VK-C series, provided it is used within recommended conditions.
Conclusion
The Omron S8VK-C06024 power supply is a compact, efficient, and reliable choice for industrial automation systems. It delivers stable 24V DC power, is globally certified, and is cost-effective for projects where high performance is needed without unnecessary extras.
For engineers and system designers, the S8VK-C06024 ensures peace of mind and long service life in demanding environments. If you’re designing or upgrading a control panel, this model is worth considering.
👉 Learn more and explore the Omron S8VK-C06024 power supply product page to see how it can fit into your application.
