When it comes to ensuring the safety and efficiency of industrial motors, the Schneider Electric TeSys GV2P14 Motor Protection Breaker stands as a benchmark for reliability. Designed for precise control and dependable protection, this breaker safeguards motors against overloads, short circuits, and phase failures – all in one compact, easy-to-install unit.
The Schneider Electric TeSys GV2P14 Motor Protection Breaker is built for performance in demanding environments, making it a staple in motor control panels, HVAC systems, pumps, conveyors, and industrial automation setups. In this article, we’ll explore its key features, technical specifications, certifications, and the wide range of applications that make it an indispensable choice for professionals worldwide.
Understanding the Schneider Electric TeSys GV2P14 Motor Protection Breaker
The Schneider Electric TeSys GV2P14 Motor Protection Breaker is a 3-pole (3P) thermal-magnetic circuit breaker designed for 3-phase AC motors. It combines manual motor starting, overload protection, and short-circuit protection in one unit. This dual protection ensures both electrical and mechanical safety during operation, reducing equipment downtime and maintenance costs.
Built under the TeSys Deca family, the GV2P14 breaker offers an adjustable overload current range between 6–10 A (In = 10 A) – ideal for small to medium-sized motor protection. Its fixed magnetic trip setting of approximately 138 A provides instant response against short-circuit events.
With a rated operational voltage (Ue) and insulation voltage (Ui) of 690 V AC, and a breaking capacity (Icu) of up to 100 kA at 230–440 V, this breaker demonstrates exceptional resilience in high-stress electrical systems. In essence, the TeSys GV2P14 is not just a protective device but a dependable guardian of motor integrity.
Technical Specifications of the Schneider Electric TeSys GV2P14 Motor Protection Breaker
Key Ratings and Electrical Data
- Poles: 3P (Three-pole)
- Trip Unit Type: Thermal-magnetic
- Adjustable Overload Range: 6–10 A (In = 10 A)
- Magnetic Trip Setting: Fixed (~138 A)
- Rated Operational Voltage (Ue): 690 V AC (50/60 Hz)
- Rated Insulation Voltage (Ui): 690 V AC
- Rated Impulse Withstand Voltage: 6 kV
- Breaking Capacity (Icu):
- 100 kA at 230–440 V AC
- 50 kA at 500 V AC
- 6 kA at 690 V AC
- Service Breaking Capacity (Ics): 100% of Icu across all voltage ratings
- Motor Power (AC-3 duty):
- 3 kW at 400 V AC
- 5 kW at 500 V AC
- 5.5 kW at 690 V AC
The Schneider Electric TeSys GV2P14 Motor Protection Breaker is crafted for durability and high performance in industrial environments, ensuring continuous protection under variable load conditions.
Mechanical and Environmental Design
- Dimensions: 89 mm (H) × 45 mm (W) × 97 mm (D)
- Mounting Options: Snap-on 35 mm DIN rail or panel-mounted (two M4 screws)
- Operating Temperature: −20 °C to +60 °C
- Storage Temperature: −40 °C to +80 °C
- Ingress Protection: IP20 (finger-safe)
- Impact Resistance: IK04
- Pollution Degree: 3 (IEC standard compliance)
These compact dimensions and rugged build make the TeSys GV2P14 an excellent fit for space-constrained control panels, without compromising reliability or accessibility.
Global Certifications and Standards Compliance
The Schneider Electric TeSys GV2P14 Motor Protection Breaker meets stringent international standards, ensuring its suitability for installations worldwide.
Compliance and Approvals
- IEC/EN 60947-2: Low-voltage circuit-breaker standard
- IEC/EN 60947-4-1: AC-3 motor protection circuit breaker (MPCB)
- Certifications:
- UL and cULus (North America)
- CSA (Canada)
- CCC (China)
- EAC (Eurasian Customs Union)
- ATEX (explosive atmosphere compatibility)
- Lloyd’s Register, Bureau Veritas, RINA, and DNV-GL (marine applications)
- UKCA (United Kingdom)
- CE mark via IECEE CB Scheme
With this level of certification, the Schneider Electric TeSys GV2P14 Motor Protection Breaker is fully compliant with international safety and performance requirements, making it ideal for global industrial projects.
Accessories and Mounting Options for TeSys GV2P14
One of the standout features of the Schneider Electric TeSys GV2P14 Motor Protection Breaker is its compatibility with a wide range of accessories. These accessories enhance functionality, user convenience, and system integration.
1. External Rotary Handle Kit (GV2APN01)
This black rotary handle kit enables door-mounted operation for the GV2P14. It offers IP54 protection, supports up to three padlocks, and allows lockout in both ON and OFF positions. This feature enhances operator safety during maintenance and isolation procedures.
2. Auxiliary Contact Blocks (GVAE11, GVAE20, GVAN11, etc.)
Auxiliary contact blocks can be easily attached to the breaker to provide NO/NC status or fault signaling. These can be connected to indicators or alarms, allowing operators to monitor breaker tripping or operational status remotely.
3. Shunt and Undervoltage Release Units (GVAS/GVAU Series)
These accessories enable remote control or automatic tripping. The shunt release allows remote tripping when energized, while the undervoltage release trips the breaker automatically when control voltage drops or is lost.
4. Mechanical Interlocks and Starter Kits
Mechanical interlocks allow coordination between multiple breakers, preventing simultaneous closure. The GV2P14 can also be paired with TeSys contactors (such as LC1D series) to form complete motor starter assemblies.
The modularity of the TeSys GV2 series allows engineers to design flexible and scalable protection systems, tailored to specific industrial needs.
Alternative Models in the TeSys GV2 Family
The Schneider Electric TeSys GV2P14 Motor Protection Breaker is part of a wider family of breakers offering different current ranges for various motor capacities:
|
Model |
Adjustable Current Range |
Rated Current (In) |
|
GV2P10 |
4.0–6.3 A |
6.3 A |
|
GV2P14 |
6–10 A |
10 A |
|
GV2P16 |
9–14 A |
10 A |
|
GV2P20 |
13–18 A |
16 A |
|
GV2P22 |
20–25 A |
20 A |
|
GV2P32 |
24–32 A |
25 A |
For higher current applications, Schneider Electric offers the TeSys GV3 and GV4 series, covering up to 63 A and beyond. This scalability ensures that designers can choose the right model for every motor size while maintaining the same robust TeSys performance standard.
Typical Applications of Schneider Electric TeSys GV2P14 Motor Protection Breaker
The Schneider Electric TeSys GV2P14 Motor Protection Breaker is highly versatile, serving in diverse industries that demand efficiency, safety, and compact design. Common applications include:
1. Industrial Automation Systems
Ideal for protecting motor-driven components in assembly lines and robotic systems, where precise control and fault isolation are critical.
2. HVAC and Pump Systems
Ensures smooth motor operation in fans, chillers, compressors, and water pump systems, preventing costly downtime due to overload or short-circuit damage.
3. Conveyors and Material Handling Equipment
Reliable protection for motors driving belts, rollers, or lifting mechanisms, reducing the risk of system-wide failures in continuous operations.
4. Machine Control Panels
Compact size and high performance make it perfect for integration in control panels, where multiple breakers manage different motor circuits efficiently.
5. Marine and Offshore Applications
With multiple marine certifications, it is well-suited for shipboard and offshore installations, offering resistance to harsh environmental conditions.
In all these environments, the Schneider Electric TeSys GV2P14 Motor Protection Breaker ensures smooth operations by combining functionality and protection in one unit.
Related Product Collections
Explore related product categories from Industrial Electrical Warehouse that complement the Schneider Electric TeSys GV2P14 Motor Protection Breaker:
Discover a comprehensive range of motor control devices including contactors, overload relays, and starters designed to enhance operational safety and performance.
Browse circuit breakers built for reliability and precision across various electrical systems, ensuring optimal fault protection for industrial applications.
Accessories – Switches & Sockets ➔
Find essential control accessories including switches, sockets, and mounting components to streamline panel installations and ensure electrical efficiency.
Conclusion: A Reliable Choice for Motor Protection
The Schneider Electric TeSys GV2P14 Motor Protection Breaker combines compact design, superior protection, and international compliance, making it the perfect solution for professionals seeking long-lasting reliability in motor control systems. Whether for automation panels, HVAC systems, or marine installations, it delivers consistent performance under demanding conditions.
For detailed specifications, compatible accessories, and installation guidelines, visit the product page of the Schneider Electric TeSys GV2P14 Motor Protection Breaker to explore its full range of capabilities and ensure your next project benefits from Schneider’s trusted protection technology.
