Description
The Festo Pressure Sensor SPAB-B2R-R18-PB-M8 is a cutting-edge solution for industrial automation, designed to meet the stringent demands of modern manufacturing environments. Engineered with precision, this sensor ensures accurate and reliable pressure measurements, critical for monitoring and controlling various industrial processes. The M8 connector provides a secure and efficient electrical connection, enhancing the sensor's compatibility and ease of integration into existing systems. Trust in Festo's commitment to quality and innovation with the SPAB-B2R-R18-PB-M8 Pressure Sensor for unparalleled performance in industrial electrical applications.
Featuring robust construction and industrial-grade components, this pressure sensor excels in harsh conditions, delivering consistent results in diverse settings. The SPAB-B2R-R18-PB-M8 is designed to withstand the rigors of industrial environments, providing long-lasting and dependable service. With its high precision and M8 connectivity, this Festo Pressure Sensor is an indispensable component for industrial automation, ensuring the efficiency and reliability required for critical electrical systems. Upgrade your industrial setup with the SPAB-B2R-R18-PB-M8 for superior pressure sensing capabilities in every application.
Festo Pressure Sensor SPAB-B2R-R18-PB-M8 Features:
- Short type code: SPAB
- Electrical Connect: 4-pin
- Electrical Connect: M8 x 1
- Electrical Connect: Plug
- Electrical Connect: Round design
- Electrical Connect: to EN 60947-5-2
- Mounting: Optional
- Mounting: Threaded
- Mounting: With accessories
- Pneumatic connection: Female thread M5
- Pneumatic connection: Male thread R1/8
- Ambient temp: -10 - 50 °C
- Analogue output: 1 - 5 V
- Authorisation: c UL us - Recognized (OL)
- Authorisation: C-Tick
- CE mark (see declaration of conformity): to EU directive for EMC
- Corrosion resistance classification CRC: 2
- Hysteresis setting range: 0 - 90 %
- Materials information, housing: ABS-reinforced
- Materials information, housing: PBT-reinforced
- Materials note: Conforms to RoHS
- Materials note: Contains PWIS substances
- Max. output current: 100 mA
- Measured variable: Relative pressure
- Measurement method: Piezoresistive pressure sensor with display
- Operating medium: Filtered, unlubricated compressed air, 40 µm filtration
- Operating status display: LCD, yellow
- Operating voltage range DC: 12 - 24 V
- Overload range: 5 bar
- Polarity protected: for operating voltage
- Precision analogue output margin in ± %FS: 5 %
- Precision analogue output zero point in ± %FS: 5 %
- Precision display FS: 1 %
- Pressure measuring range, final value: 1 bar
- Pressure measuring range, initial value: -1 bar
- Product weight: 45 g
- Protection against manipulation: PIN-Code
- Protection class: IP40
- Reproducibility, analogue value: 0.2 %
- Setting options: Teach-In
- Setting options: Via display and buttons
- Short circuit strength: Yes
- Switch output: PNP
- Switching element function: Switchable
- Switching function: Freely programmable
- Switching point reproducibility: 0.1 %
- Threshold value setting range: 0 - 100 %
- Type of display: Illuminated LCD multicoloured
- Unit(s) that can be displayed: bar
- Unit(s) that can be displayed: inchH2O
- Unit(s) that can be displayed: inchHg
- Unit(s) that can be displayed: kgf/cm²
- Unit(s) that can be displayed: kPa
- Unit(s) that can be displayed: mmHg
- Unit(s) that can be displayed: psi
