Description
The Festo Proportional Directional Control Valve MPYE-5-1/8-LF-010-B stands as a pinnacle of industrial electrical engineering, offering precise and efficient control in various applications. Crafted with cutting-edge technology, this directional control valve ensures proportional flow regulation with unmatched reliability. The valve's advanced design incorporates high-quality materials, making it suitable for demanding industrial environments. Whether used in automated manufacturing processes or complex machinery, the Festo MPYE-5-1/8-LF-010-B excels in providing seamless and responsive electrical control, ensuring optimal performance and longevity.
Designed for compatibility with industrial systems, the Festo Proportional Directional Control Valve features a robust construction that meets the rigorous standards of modern electrical engineering. The MPYE-5-1/8-LF-010-B is equipped with precision components to deliver accurate and proportional control over fluid flow, enhancing overall system efficiency. Its 1/8-inch size and LF design make it ideal for integration into industrial setups, while the valve's 010 flow rating ensures precise regulation of fluid movement. Trust in the Festo MPYE-5-1/8-LF-010-B for reliable and high-performance proportional directional control in your industrial electrical applications.
Festo Proportional Directional Control Valve MPYE-5-1/8-LF-010-B Features:
- Short type code: MPYE
- Valve Function: 5/3
- Valve Function: closed
- Electrical Connect: 4-pin
- Electrical Connect: M12 x 1
- Electrical Connect: Plug
- Electrical Connect: Round design
- Mounting: With through hole
- Type of reset: Magnetic spring
- Ambient temp: 0 - 50 °C
- Assembly position: Any
- Authorisation: C-Tick
- b value: 0.12
- C value: 1.65 l/sbar
- CE mark (see declaration of conformity): to EU directive for EMC
- Corrosion resistance classification CRC: 2
- Design structure: Piston slide
- Flow direction: non reversible
- Materials information for cover: ABS
- Materials information for cover: Coated
- Materials information for seals: NBR
- Materials information, housing: Aluminium
- Materials information, housing: Anodised
- Max. hysteresis: 0.4 %
- Medium temperature: 5 - 40 °C
- Nominal size: 4 mm
- Operating medium: Filtered, unlubricated compressed air, 5 µm filtration
- Operating Pressure: 0 - 10 bar
- Operating voltage range DC: 17 - 30 V
- Pneumatic connection, port 1: G1/8
- Pneumatic connection, port 2: G1/8
- Pneumatic connection, port 3: G1/8
- Pneumatic connection, port 4: G1/8
- Pneumatic connection, port 5: G1/8
- Polarity protected: for all electrical connections
- Protection class: IP65
- Residual ripple: 5 %
- Safety instructions: MPYE safety position: If the power supply cable is interrupted, travel occurs to the closed mid-posi
- Sealing principle: Hard
- SETPOINT/ACTUAL values: Voltage type 0 - 10 V
- Standard nominal flow rate: 350 l/min
- Type of actuation: Electrical
- Type of piloting: Direct
