NHP Miniature Circuit Breaker 3-Pole DTCB6320C with 32A 30MA 3PN DSRCM32303PN


Condition and Packaging: USED - In-House
Price:
Sale Price$81.00 USD
Stock:
Only 1 unit left
  • Free Standard Shipping Worldwide NO Minimum Spend
  • Free Express Shipping Worldwide on Orders over $200 USD
  • Every item you choose is carefully handpicked and packed by our dedicated team in-house
  • 30 Days Return policy

Description

Introducing the SNHP Miniature Circuit Breaker 3-Pole DTCB6320C with RCD Clip On 32A 30MA 3PN DSRCM32303PN, a cutting-edge solution for industrial electrical systems. Engineered for optimal performance and safety, this circuit breaker is designed to meet the stringent requirements of the industrial sector. The 3-pole configuration ensures efficient protection against overcurrents, while the 32A rating makes it suitable for a wide range of electrical applications.

Featuring a built-in RCD (Residual Current Device) with a 30mA sensitivity and a convenient clip-on design, the DSRCM32303PN adds an extra layer of protection, detecting and mitigating earth leakage currents. The high-quality construction and DSRCM32303PN designation signify compliance with industrial standards, providing reliability and peace of mind in electrical installations. Upgrade your electrical systems with the SNHP Miniature Circuit Breaker for a robust and dependable solution in industrial settings.

NHP Miniature Circuit Breaker 3-Pole DTCB6320C with RCD Clip On 32A 30MA 3PN DSRCM32303PN Features:

  • SNHP Miniature Circuit Breaker
  • 3-Pole Configuration 3P + N
  • DTCB6320C Model
  • RCD Clip On
  • 32A Rating
  • 30mA Sensitivity
  • 3PN DSRCM32303PN Designation
  • Industrial-grade Construction
  • Miniature Circuit Breaker DTCB6320C
  • Dielectric strength: 2.5kV
  • Rated frequency: 50/60 Hz
  • Relative humidity, Max: 95
  • IP rating, Inside: IP40
  • IP rating, Outside: IP20
  • Mounting: DIN-35 rail mount
  • Flammability rating (UL94): UL 94 V-2
  • Shock rating: IEC 60068-2-27
  • Vibration rating: IEC 60077-16-3
  • Insulation resistance: 10000
  • Electrical service life at Un, In: 10000
  • Mechanical service life: 20000
  • Shock acceleration (Max.): 40
  • Shock duration (Max.): 5
  • Operating temperature, Max: 55
  • Operating temperature, Min: -25
  • Storage temperature, Max: 55
  • Storage temperature, Min: -55
  • Tightening torque, Bottom, Nominal: 4.5
  • Tightening torque, Top, Nominal: 4.5
  • Trip Curve: C
  • RCD Clip On DSRCM32303PN
  • Component Type Power Distribution & Protection: RCD
  • Number of Poles versus Modules: 2
  • In, Rated Current at 30°C: 32 A @30°C
  • Depth: 76 mm
  • Height: 86 mm
  • Dielectric Strength: 2500VAC
  • Grid Distance (Safety Difference Between 2 Devices): 35 mm
  • Rated Frequency: 50 / 60 Hz
  • Relative Humidity, Max: 95 %RH
  • Mounting: DIN-35 Rail Mount

To set the proper expectation, we use different types of packaging for our products.

A. NEW- Manufacturer Packaging

Products with manufacturer's packaging still intact.
We ship these products as is, using the manufacturer's packaging.

B. NEW (New Never Used)Custom Packaging

New products with malformed or scraped packaging
When the manufacturer's packaging suffers defects or scrapes during shipping to our warehouse, we replace it with customized packaging to ensure the safety of the products. Rest assured that these products are brand-new, never used, and thoroughly tested before being shipped.

C. USEDIn-House

The manufacturer's packaging is no longer available
Used products are shipped using in-house packaging. We guarantee that all used products are tested by our licensed electrical engineers before shipping to ensure they are in good condition and fully functional.

We offer a simple 30-day return policy for your added peace of mind. For questions, contact us.

Important Notice for Customers:

All goods sold on our website must be installed by a suitably qualified person in your area. This ensures the safety and compliance of the installation with local electrical codes, regulations, and standards.

Product Description and Condition:

We strive to accurately describe all listings and provide the most accurate images whenever possible. However, unless otherwise stated, all images are for illustration purposes and reference only. Some of the boxes may be dusty and/or torn due to storage on shelves, but the items themselves are fine. Some products may even have minor surface marks, scuffs or scratches. Any such wear due to handling is purely superficial and will not interfere with the correct functioning of the device.

For any questions or further information, please contact our customer service team.
