In the ever-evolving world of industrial automation, sensors play a critical role in ensuring accuracy, reliability, and efficiency. One of the most dependable choices in this category is the Omron Inductive Proximity Sensor 12-24VDC PNP Output IP67 E2B-M18KS08-M1-B1. Known for its durability, precision, and compatibility across industries, this sensor is a cost-effective solution for a wide range of applications.
This article will take an in-depth look at the specifications, applications, certifications, and mounting accessories for the E2B-M18KS08-M1-B1 sensor. By the end, you’ll know exactly why this sensor stands out and how it can improve your operations.
What is the Omron E2B-M18KS08-M1-B1?
The Omron E2B-M18KS08-M1-B1 is part of Omron’s E2B cylindrical proximity sensor series. Built with an M18 short-barrel nickel-plated brass housing, it is compact yet powerful, with a sensing distance of up to 8 mm. Designed with a PNP normally-open output and an M12 connector, it is one of the most versatile inductive sensors available for standard industrial environments.
This inductive proximity sensor is IP67-rated, meaning it is dust-tight and resistant to water ingress, making it reliable even in environments exposed to oil mist, vibrations, or temporary immersion in water.
For industries seeking dependable and economical automation solutions, the Omron inductive proximity sensor E2B-M18KS08-M1-B1 delivers performance and longevity at a competitive price point.
Key Technical Specifications
To help you understand its performance, here are the main technical specifications of the Omron inductive proximity sensor 12-24VDC PNP output IP67 E2B-M18KS08-M1-B1:
· Sensing Distance: 8 mm (shielded, flush-mount)
· Supply Voltage: 10–30 VDC
· Output Type: PNP, 3-wire normally open (NO)
· Max Load Current: 200 mA
· Switching Frequency: 500 Hz
· Residual Voltage: ≤ 2 V at 200 mA
· Operating Temperature: -25°C to +70°C
· Indicator: 360° visible yellow LED
· Housing Material: Nickel-plated brass
· Connection: M12 4-pin connector
· Protection: IP67 (dust-tight and waterproof)
These specifications make it ideal for machine tools, conveyors, and general automation systems where precise detection of metallic objects is essential.
Dimensions and Mounting
The E2B-M18KS08-M1-B1 is designed with compact installation in mind:
· Overall Length: 59 mm
· Threaded Portion Length: 39 mm
· Thread Diameter: M18
· Mounting Style: Flush (shielded)
· Connector: M12 x 1 at the back of the sensor
Thanks to its short-barrel design, the sensor is particularly useful in tight spaces. It comes with two mounting nuts and a toothed washer, but for advanced installations, Omron also provides optional mounting brackets.
Compatible Accessories and Mounting Hardware
To maximise the performance of the E2B-M18KS08-M1-B1, consider pairing it with Omron-approved accessories:
· Y92E-B18 Mounting Bracket – Designed for M18 sensors, ensures stable and accurate alignment.
· M12 Cordsets (XS2 or GX Series) – Provide secure and sealed connections with different cable lengths and orientations.
· Locknuts & Washers – Supplied with the sensor for quick mounting.
These accessories make installation faster and reduce downtime during maintenance.
Typical Applications of the Omron Inductive Proximity Sensor
The Omron inductive proximity sensor E2B-M18KS08-M1-B1 is widely used across industries for detecting metallic objects. Common applications include:
· Machine Tools: Detecting tool position and workpiece presence.
· Packaging Equipment: Confirming metallic parts, foils, or lids are in place.
· Assembly Lines: Position sensing of metal parts in automation systems.
· Automotive Manufacturing: Detecting car body parts, engine blocks, or fixtures.
· Conveyors & Material Handling: Counting and detecting items with metal components.
With its 500 Hz response frequency and robust design, it is suitable for high-speed industrial environments.
Certifications and Compliance
The E2B-M18KS08-M1-B1 sensor complies with global standards:
· IP67 Protection – Tested under IEC 60529 for dust and water resistance.
· CE Marked – Conforms to European safety and EMC standards.
· UL Listed – Certified for industrial use in the USA and Canada.
· RoHS Compliant – Free of hazardous substances.
· EN 60947-5-2 – Meets the international standard for proximity sensors.
These certifications guarantee that the sensor is safe, environmentally friendly, and globally deployable.
Why Choose Omron’s E2B Series?
Omron’s E2B series is designed to provide reliable performance in standard industrial environments without the extra cost of high-end features that are not always necessary. The E2B-M18KS08-M1-B1 offers just the right balance between durability, affordability, and ease of installation.
If you are looking for additional industrial automation products, explore related categories at Industrial Electrical Warehouse such as:
Conclusion
The Omron inductive proximity sensor 12-24VDC PNP output IP67 E2B-M18KS08-M1-B1 is is a robust and cost-effective choice for general industrial applications. With an 8 mm sensing distance, reliable PNP output, and rugged IP67 design, it delivers accuracy and durability in demanding environments. Backed by Omron’s legacy of quality, it remains one of the best solutions for machine tools, packaging, conveyors, and assembly lines.
Whether you’re upgrading existing systems or designing a new automation line, the E2B-M18KS08-M1-B1 ensures performance, compliance, and long-term reliability.
