The Schneider Electric TeSys GV2-P06 Motor Circuit Breaker is a compact yet powerful component designed for reliable motor protection and manual control in industrial systems. Built under Schneider Electric’s trusted TeSys Deca series, this breaker offers superior safety, ease of installation, and high short-circuit capacity, making it a preferred choice for engineers and plant operators.
In this blog, we will explore every detail of the Schneider Electric TeSys GV2-P06, including its technical specifications, compliance, applications, compatible accessories, and why it remains an essential part of efficient motor management systems.
What is the Schneider Electric TeSys GV2-P06 Motor Circuit Breaker?
The Schneider Electric TeSys GV2-P06 Motor Circuit Breaker is a three-pole thermal-magnetic manual starter that provides protection for motors drawing up to 1.6A. It combines isolation, motor control, and overload/short-circuit protection in one compact unit.
Engineered to safeguard small three-phase motors, it ensures consistent performance even in harsh industrial environments. Its adjustable thermal trip range of 1.0 to 1.6A and a fixed magnetic trip at 22.5A make it versatile for various applications such as pumps, fans, and compressors.
Technical Overview of the Schneider Electric TeSys GV2-P06
The GV2-P06 is part of Schneider’s renowned TeSys Deca GV2 series, known for high reliability, modularity, and compliance with international standards.
Key Specifications:
- Type: 3-pole thermal-magnetic motor circuit breaker
- Rated Operational Voltage (Ue): 690 VAC (50/60 Hz)
- Rated Insulation Voltage (Ui): 690 VAC
- Impulse Withstand Voltage (Uimp): 6 kV
- Adjustable Thermal Trip Range: 1.0–1.6A
- Magnetic Trip Setting: Fixed at 22.5A
- Short-Circuit Breaking Capacity (Icu): 100 kA at 230–690 VAC (IEC 60947-2)
- Service Breaking Capacity (Ics): 100% of Icu
- Utilization Category: AC-3
- Operational Temperature Range: –20 °C to +60 °C
- Storage Temperature: –40 °C to +80 °C
- Ingress Protection: IP20 (IEC 60529)
- Impact Resistance: IK04
- Dimensions: 45 mm (W) × 89 mm (H) × 97 mm (D)
- Weight: ~0.32 kg
- Tightening Torque: 1.7 N·m
The Schneider Electric TeSys GV2-P06 Motor Circuit Breaker also features a rotary handle, allowing manual ON/OFF control and a clear visual indication of isolation.
Performance and Reliability
The TeSys GV2-P06 excels in providing dependable motor protection due to its thermal-magnetic protection system:
- Thermal (Overload) Protection: Automatically trips when the motor draws excessive current over time, protecting windings from heat damage.
- Magnetic (Short-Circuit) Protection: Responds instantly to severe current surges caused by short circuits.
With a breaking capacity of up to 100 kA, it ensures operational safety in demanding industrial environments. The phase-loss sensitivity prevents motor damage caused by single-phase failure—a critical feature in motor protection. Learn more about short-circuit breaking capacity (Icu/Ics).
Compliance and Certifications
The Schneider Electric TeSys GV2-P06 Motor Circuit Breaker complies with major international safety and performance standards:
- IEC 60947-2 (Circuit Breakers)
- IEC 60947-4-1 (Motor-Starters)
- UL 508 (Industrial Control Equipment)
- CSA (Canadian Standards Association)
- CCC (China Compulsory Certification)
- EAC (Eurasian Conformity)
- ATEX (Hazardous Atmospheres)
- Lloyd’s Register, DNV-GL, RINA, Bureau Veritas (Marine Certifications)
- CE and UKCA Marked
These certifications ensure the GV2-P06 meets rigorous industrial and marine application requirements worldwide.
Design and Construction
The GV2-P06 embodies Schneider Electric’s engineering excellence, with a robust, ergonomic design for reliability and user safety.
Compact and Durable Design
At only 45 mm wide, the GV2-P06 is optimized for compact control panels and motor control centers. Its high-strength housing and reliable terminals withstand vibrations and thermal stress.
Easy Operation
The rotary handle enables smooth manual switching between ON, OFF, and TRIPPED positions, with clear markings for operator safety.
Maintenance-Friendly
Screw-clamp terminals with multi-standard screws and optional EverLink terminals enhance connection stability and simplify maintenance.
Accessories for Enhanced Functionality
Schneider Electric offers a full range of compatible accessories for the TeSys GV2-P06 Motor Circuit Breaker, allowing users to tailor it for specific operational needs:
- Auxiliary Contact Blocks – For signaling and control (1 NO + 1 NC)
- Shunt Trip (GV2-AX) – Enables remote tripping
- Undervoltage Release (GV2-AU) – Trips the breaker when supply voltage falls below a threshold
- Extended Rotary Handle Kits (GV2-APN) – For front-door mounting with IP54 protection
- Padlock Attachments – For safety lockout in maintenance
- Combination Blocks – For interlocking or contactor interfacing
These modular accessories make the Schneider Electric TeSys GV2-P06 adaptable for both standalone use and integrated control systems.
Installation and Mounting
Installing the Schneider Electric TeSys GV2-P06 is quick and versatile:
- Mounting Options: 35 mm DIN rail or direct panel mounting (M4 screws)
- Orientation: Can be mounted vertically or horizontally
- Connection: Screw-clamp terminals for secure wiring
For panel-mounted applications, an optional short shaft and front-door handle kit are available, ensuring safe manual isolation from outside the panel.
Installation Tips:
- Maintain adequate ventilation space.
- Verify torque tightening (1.7 N·m) for reliable connection.
- Ensure conformity to IEC 60947-4-1 clearance guidelines.
Applications of Schneider Electric TeSys GV2-P06 Motor Circuit Breaker
The GV2-P06 Motor Circuit Breaker is widely used across industries due to its versatility and reliability.
Common Use Cases:
- Pumps and Compressors: Prevents motor burnout due to overload or phase failure.
- Fans and Blowers: Provides consistent protection in HVAC and ventilation systems.
- Conveyors and Machinery: Offers precise motor control and fault isolation.
- Automation Panels: Ideal for compact motor control and protection.
- Mining and Power Systems: Withstands demanding conditions and high fault currents.
In these scenarios, the Schneider Electric TeSys GV2-P06 ensures continuous productivity and minimizes downtime.
Comparing the GV2-P06 with Other Models in the TeSys GV2 Range
The TeSys GV2 lineup offers a wide current range for different motor sizes:
|
Model |
Current Range (A) |
Typical Motor Power at 400V |
Application |
|
GV2-P05 |
0.63–1.0 |
0.25 kW |
Small control motors |
|
GV2-P06 |
1.0–1.6 |
0.37 kW |
Standard small motors |
|
GV2-P07 |
1.6–2.5 |
0.55 kW |
Light machinery |
|
GV3 |
5–32 |
3.0–16 kW |
Larger motor setups |
This modular design allows easy scalability and system standardization for various motor control applications.
Why Choose the Schneider Electric TeSys GV2-P06 Motor Circuit Breaker?
1. Comprehensive Protection
The Schneider Electric TeSys GV2-P06 offers overload, short-circuit, and phase-loss protection in a single unit.
2. Compact and Efficient Design
It minimizes panel space while maintaining powerful performance and simple installation.
3. Global Standards Compliance
Its certifications guarantee compatibility with global industrial norms, ensuring safe international use.
4. Versatile and Expandable
Optional accessories and compatible GV2/GV3 systems make it easy to expand or customize.
5. Trusted Brand Reliability
As part of Schneider Electric’s TeSys series, it benefits from decades of proven performance in automation and power systems.
Environmental Considerations and Durability
The TeSys GV2-P06 is engineered for sustainability and durability. With a low power loss of ~2.5 W per pole and high thermal tolerance, it meets efficiency standards while minimizing operational heat. Its environmental resilience makes it suitable for both tropical and industrial conditions.
Related Product Collections You May Like
Explore related product collections from Industrial Electrical Warehouse that complement the Schneider Electric TeSys GV2-P06 Motor Circuit Breaker:
A curated range of starters, contactors, and drives ideal for efficient and reliable motor control applications.
➤ Control Relays (Motor Control Equipment)
Complement your motor circuit breakers with dependable control relays to enhance system automation and safety.
➤ Sensors
Find precise and durable sensors for industrial automation systems that integrate seamlessly with motor control setups.
Conclusion: Reliable Motor Protection with Schneider Electric TeSys GV2-P06
The Schneider Electric TeSys GV2-P06 Motor Circuit Breaker stands out as a dependable and flexible solution for protecting small motors in a wide range of industrial and commercial settings. Its combination of compact size, robust protection, international certifications, and modular accessories makes it ideal for modern control systems.
If you’re looking to integrate reliable motor protection into your electrical system, the TeSys GV2-P06 offers performance you can trust.
✨ Explore the Schneider Electric TeSys GV2-P06 Motor Circuit Breaker and other TeSys GV2 models at Industrial Electrical Warehouse to find the perfect fit for your application.
